| Number | Type | Part No. | Specification |
| 1 | WOODMASTER SQUARE DRIVE COUNTERSUNK DECKING SCREWS | ADS-A4-50 | 4.2 X 50 SQUARE DRIVE COUNTERSUNK WOODMASTER DECKING SCREW A4 STAINLESS STEEL |
| 2 | WOODMASTER SQUARE DRIVE COUNTERSUNK DECKING SCREWS | ADS-A4-63 | 4.2 X 63 SQUARE DRIVE COUNTERSUNK WOODMASTER DECKING SCREW A4 STAINLESS STEEL |
| 3 | WOODMASTER SQUARE DRIVE COUNTERSUNK DECKING SCREWS | ADS-A4-75 | 4.2 X 75 SQUARE DRIVE COUNTERSUNK WOODMASTER DECKING SCREW A4 STAINLESS STEEL |
| Parameter | |||||||||
| Gauge / Metric | Lo | Dm | Drive | Dh | P | Lt | A1 degrees | A2 degrees | A3 degrees |
| #8 (4.20) | 50 | 4.35-4.05 | #2 | 8.43-7.41 | 2.33-2.07 | 36-34 | 29-23 | 63-57 | 82-80 |
| #8 (4.20) | 63 | 4.35-4.05 | #2 | 8.43-7.41 | 2.33-2.07 | 46-44 | 29-23 | 63-57 | 82-80 |
| #8 (4.20) | 75 | 4.35-4.05 | #2 | 8.43-7.41 | 2.33-2.07 | 56-54 | 29-23 | 63-57 | 82-80 |
